A Comprehensive Exploration of Partial Discharge in Power Transformers and GIS

This article delves deeper into the intricacies of partial discharge, exploring advanced analysis techniques, the role of artificial intelligence, integration with other diagnostics, on-line versus off-line testing methodologies, real-world case studies, emerging trends in monitoring, economic implications, the influence of environmental factors, and the specific characteristics of PD associated with various defect types.

By Lamothe Paris
9 min read
A Comprehensive Exploration of Partial Discharge in Power Transformers and GIS

The integrity of high-voltage electrical equipment, such as power transformers and Gas-Insulated Switchgear (GIS), is paramount for the stability and reliability of power grids. Partial discharge (PD), a localized electrical breakdown within the insulation system, serves as a critical indicator of potential insulation degradation and a precursor to major equipment failures.1 This article delves deeper into the intricacies of partial discharge, exploring advanced analysis techniques, the role of artificial intelligence, integration with other diagnostics, on-line versus off-line testing methodologies, real-world case studies, emerging trends in monitoring, economic implications, the influence of environmental factors, and the specific characteristics of PD associated with various defect types.

Advanced Partial Discharge Analysis: Unveiling Deeper Insights

While basic PD testing provides essential information about the presence and magnitude of discharges, advanced analysis techniques offer a more nuanced understanding of the underlying insulation conditions.3

  • Phase-Resolved Partial Discharge (PRPD) and Time-Resolved Partial Discharge (TRPD) Patterns:PRPD patterns, which map PD pulses against the phase angle of the AC voltage, are fundamental for defect identification.1 Different defect types, such as voids, corona, and surface discharges, exhibit characteristic PRPD signatures.6 TRPD patterns, on the other hand, analyze PD pulses over time, proving valuable for DC systems and tracking the evolution of PD activity.9
  • Statistical and Trend Analysis: Analyzing statistical parameters like discharge magnitude distribution, repetition rates, and pulse timing can quantify insulation degradation severity.10 Trend analysis, monitoring changes in PD parameters over time, is crucial for predicting the progression of defects and planning timely maintenance.13
  • Wavelet Transforms: These advanced mathematical tools excel at analyzing the transient nature of PD signals, decomposing them into different frequency components. This allows for enhanced noise separation and feature extraction, aiding in the precise identification of PD sources and types.
  • Pulse Sequence Analysis (PSA): By examining the correlation between consecutive PD pulses, PSA can reveal intricate details about the discharge mechanisms and the nature of the insulation defect.14

The Ascending Role of Artificial Intelligence in Partial Discharge Diagnostics

Artificial Intelligence (AI) and machine learning are revolutionizing the field of PD analysis, offering automated and enhanced diagnostic capabilities.15

  • Automated Pattern Recognition: AI algorithms, including neural networks and support vector machines (SVMs), can be trained to automatically recognize complex PRPD and TRPD patterns associated with various defect types, significantly improving diagnostic speed and accuracy.
  • Intelligent Noise and Source Separation: AI techniques can effectively distinguish genuine PD signals from background noise and even separate PD signals originating from multiple concurrent sources, a significant challenge in on-site measurements.
  • Predictive Severity Assessment: Machine learning models can analyze various PD parameters to assess the severity of insulation degradation and predict the likelihood of future failures, enabling proactive and risk-based maintenance strategies.18
  • Enhanced Localization Accuracy: AI algorithms are being employed to refine the accuracy of PD source localization using data from multiple sensors, such as acoustic and Ultra-High Frequency (UHF) sensors.19

Synergistic Benefits: Integrating Partial Discharge Testing with Other Diagnostic Methods

For a holistic assessment of the health of power transformers and GIS, partial discharge testing is often integrated with other diagnostic techniques.21

  • Dissolved Gas Analysis (DGA): DGA identifies gases dissolved in transformer oil that are produced by insulation breakdown, including that caused by PD. Combining PD testing with DGA provides a more comprehensive understanding of insulation health. For instance, elevated levels of hydrogen and methane in DGA alongside significant PD activity may indicate severe internal discharging.22
  • Frequency Response Analysis (FRA): FRA detects mechanical and electrical changes within transformer windings and the core.25 Integrating PD testing with FRA can help differentiate between insulation issues (indicated by PD) and structural problems within the transformer. The novel Partial-Discharge-Activated Impulse Frequency Response Analysis (PD-IFRA) technique specifically aims to detect PD-related impedance deviations.

On-Line vs. Off-Line Partial Discharge Testing: Tailoring the Approach

Partial discharge testing can be conducted while the equipment is energized (on-line) or de-energized (off-line), each approach offering distinct advantages and disadvantages.

Feature On-Line Testing Off-Line Testing
Equipment State Energized, under normal operating conditions De-energized, isolated from the power system
Advantages Real-time assessment, detects issues under load, continuous monitoring possible Lower noise levels, controlled voltage application, higher sensitivity to some defects
Disadvantages Higher noise levels, can be challenging to pinpoint PD source, lower sensitivity Requires equipment outage, may not detect issues only occurring under load
Applications Condition monitoring, detecting issues in service Acceptance testing, diagnostic testing, quality control

Real-World Insights: Case Studies in Partial Discharge Detection

Numerous case studies underscore the practical significance of partial discharge testing in preventing failures and ensuring the longevity of critical equipment.

  • Power Transformers: On-line PD monitoring has successfully detected insulation defects in large power transformers, enabling timely repairs and averting catastrophic breakdowns. These studies often utilize a combination of electrical, acoustic, and UHF methods for comprehensive analysis and precise source localization.28
  • GIS Switchgear: UHF and acoustic methods have proven effective in identifying various defect types in GIS, including floating particles, protrusions, and voids. On-line monitoring plays a crucial role in tracking the development of PD activity over time, allowing for proactive maintenance interventions.29

Emerging Trends: The Future of Partial Discharge Monitoring

The field of partial discharge monitoring is dynamic, with several key trends shaping its future.

  • Proliferation of On-Line Monitoring Systems: Continuous on-line monitoring is gaining traction due to its ability to provide real-time data and detect intermittent PD activity, offering a more comprehensive assessment of equipment health.30
  • Integration of IoT and Cloud Technologies: The incorporation of IoT-enabled PD sensors and cloud-based platforms facilitates remote monitoring, secure data storage, and advanced analytics, enabling sophisticated predictive maintenance strategies.30
  • Advancements in Sensor Technology: Miniaturization and cost reduction of sensors, along with the development of wireless and non-invasive sensor technologies like Transient Earth Voltage (TEV) and UHF, are making PD monitoring more accessible and easier to deploy.17
  • Sophisticated Noise Suppression Techniques: Ongoing research and development are yielding advanced signal processing and noise cancellation algorithms to enhance the accuracy of PD detection, particularly in challenging on-site environments.

Economic Advantages: The Tangible Benefits of Partial Discharge Management

Investing in partial discharge testing and monitoring yields significant economic returns.

  • Prevention of Costly Failures: Early detection and mitigation of insulation defects prevent catastrophic equipment failures, leading to substantial savings in repair or replacement costs and minimizing prolonged downtime.33
  • Optimization of Maintenance Costs: Condition-based maintenance driven by PD data allows for targeted interventions only when necessary, optimizing maintenance schedules and reducing unnecessary expenditures.32
  • Extension of Equipment Lifespan: By addressing PD activity in its early stages, the degradation of insulation is slowed, significantly extending the operational life of expensive assets like transformers and GIS.33
  • Enhanced Power System Reliability: Preventing unexpected equipment failures through proactive PD monitoring contributes to a more stable and reliable power supply, minimizing disruptions for consumers and industries.33

The Influence of Environmental Factors on Partial Discharge Activity

Environmental conditions play a crucial role in influencing partial discharge activity within electrical equipment.

  • Humidity: High humidity can increase surface conductivity, promoting surface discharges and tracking. Moisture ingress can also exacerbate internal discharges.
  • Temperature: Temperature fluctuations can alter the dielectric properties of insulation materials and affect the inception voltage of partial discharges.
  • Pressure: In gas-insulated equipment, gas pressure directly impacts the breakdown strength of the insulating gas, influencing the occurrence of PD.36
  • Contamination: The presence of dust, dirt, salt, and other contaminants on insulation surfaces can create conductive pathways, initiating surface discharges and accelerating insulation degradation.

Decoding the Signals: Specific PD Characteristics for Different Defect Types

Different types of insulation defects often exhibit unique partial discharge characteristics, providing valuable clues for accurate diagnosis.

  • Voids: Typically manifest as repetitive discharges concentrated around the rising and falling edges of the AC voltage waveform.
  • Corona: Often characterized by discharges occurring near the peaks of the voltage waveform, with a relatively consistent repetition rate.
  • Surface Discharge: Can exhibit a wide range of patterns depending on the nature and extent of contamination and surface imperfections.
  • Floating Electrodes: Tend to produce discharges at specific voltage levels that may appear and disappear depending on voltage fluctuations and charge accumulation.
  • Moving Particles: Generate erratic and burst-like discharge patterns that are not consistently synchronized with the AC voltage phase.
  • Protrusions: Often cause discharges concentrated around the voltage peaks due to the high electric field concentration at the sharp point.

Conclusion: Embracing a Proactive Approach with Partial Discharge Management

A comprehensive understanding of partial discharge, coupled with the implementation of regular and advanced PD testing and monitoring programs, is indispensable for ensuring the long-term reliability, safety, and economic viability of power transformers and GIS. By leveraging the insights gained from PD analysis, technical managers and maintenance engineers can make informed decisions, proactively address potential insulation weaknesses, prevent catastrophic failures, extend equipment lifespan, and contribute to a more resilient and dependable power infrastructure.13 It is crucial to consult with qualified professionals who possess the necessary expertise and specialized equipment for accurate PD testing, analysis, and the development of effective maintenance strategies tailored to your specific needs.

Works cited

  1. Interpretable Detection of Partial Discharge in Power Lines with Deep Learning - PMC, accessed May 18, 2025, https://pmc.ncbi.nlm.nih.gov/articles/PMC8003486/

  2. The Evolution of Partial Discharge Testing in Electrical Equipment - NETA World Journal, accessed May 18, 2025, https://netaworldjournal.org/the-evolution-of-partial-discharge-testing-in-electrical-equipment/

  3. Research of GIS partial discharge type evaluation based on convolutional neural network, accessed May 18, 2025, https://pubs.aip.org/aip/adv/article/10/8/085305/992500/Research-of-GIS-partial-discharge-type-evaluation

  4. Identification of Partial Discharge Sources by Feature Extraction from a Signal Conditioning System - PMC, accessed May 18, 2025, https://pmc.ncbi.nlm.nih.gov/articles/PMC11014056/

  5. On-site Partial Discharge Testing of Transformers - Type here the title of your Paper, accessed May 18, 2025, https://cigre.ca/papers/2021/paper%20441.pdf

  6. Partial Discharge Source Classification in Power Transformers: A Systematic Literature Review - MDPI, accessed May 18, 2025, https://www.mdpi.com/2076-3417/14/14/6097

  7. Best Partial Discharge Monitoring System for Transformers ..., accessed May 18, 2025, https://www.fjinno.net/otq/best-partial-discharge-monitoring-system-for-transformers-advanced-solutions-for-critical-assets/

  8. Guide for electrical Partial Discharge Measurements in compliance to IEC 60270 - eCIGRE, accessed May 18, 2025, https://www.e-cigre.org/publications/detail/366-guide-for-electrical-partial-discharge-measurements-in-compliance-to-iec-60270.html

  9. Partial Discharge Analysis of Gas Insulated Systems at High Voltage AC and DC | Request PDF - ResearchGate, accessed May 18, 2025, https://www.researchgate.net/publication/273395187_Partial_Discharge_Analysis_of_Gas_Insulated_Systems_at_High_Voltage_AC_and_DC

  10. Journal Paper on Partial Discharge Monitoring? - ResearchGate, accessed May 18, 2025, https://www.researchgate.net/post/Journal-Paper-on-Partial-Discharge-Monitoring

  11. Overview and Partial Discharge Analysis of Power Transformers: A Literature Review - SciSpace, accessed May 18, 2025, https://scispace.com/pdf/overview-and-partial-discharge-analysis-of-power-5fz54kob3r.pdf

  12. Statistical Analysis of Partial Discharges - DergiPark, accessed May 18, 2025, https://dergipark.org.tr/tr/download/article-file/458709

  13. A Review Partial Discharge Activity in Electrical Insulation - CiteSeerX, accessed May 18, 2025, https://citeseerx.ist.psu.edu/document?repid=rep1&type=pdf&doi=7fc4ce0e48c1e4ac1cfac2978c2991eb34823973

  14. (PDF) Understanding Partial Discharge Behavior from the Memory Effect Induced by Residual Charges: A Review - ResearchGate, accessed May 18, 2025, https://www.researchgate.net/publication/342352689_Understanding_Partial_Discharge_Behavior_from_the_Memory_Effect_Induced_by_Residual_Charges_A_Review

  15. The pattern recognition of multisource partial discharge in transformers based on parallel feature domain | IET Science, Measurement & Technology, accessed May 18, 2025, https://digital-library.theiet.org/doi/full/10.1049/smt2.12018

  16. Recognition of partial discharge in GIS based on image feature fusion - AIMS Press, accessed May 18, 2025, http://www.aimspress.com/article/doi/10.3934/energy.2024052?viewType=HTML

  17. Low-Cost Online Partial Discharge Monitoring System for Power Transformers - PMC, accessed May 18, 2025, https://pmc.ncbi.nlm.nih.gov/articles/PMC10098812/

  18. Interpretation of partial-discharge-activated frequency response analysis for transformer diagnostics - University of Johannesburg, accessed May 18, 2025, https://ujcontent.uj.ac.za/esploro/outputs/journalArticle/Interpretation-of-partial-discharge-activated-frequency-response-analysis/9952109607691

  19. A Contemporary Review of High Voltage Partial Discharge Detection and Recognition Techniques - Semarak Ilmu Publishing, accessed May 18, 2025, https://semarakilmu.com.my/journals/index.php/fluid_mechanics_thermal_sciences/article/download/2100/2238/19132

  20. Partial Discharge Testing (PD Testing) | EA Technology Americas, accessed May 18, 2025, https://eatechnology.com/americas/resources/faq/partial-discharge-testing-pd-testing/

  21. Measurements on partial discharge in on-site operating power transformer: a case study | IET Generation, Transmission & Distribution, accessed May 18, 2025, https://digital-library.theiet.org/doi/full/10.1049/iet-gtd.2017.1551

  22. Towards Precise Interpretation of Oil Transformers via Novel Combined Techniques Based on DGA and Partial Discharge Sensors - PubMed Central, accessed May 18, 2025, https://pmc.ncbi.nlm.nih.gov/articles/PMC8005011/

  23. Partial Discharge Detection and Location in Transformers Using UHF Techniques - High Frequency Diagnostics and Engineering Ltd, accessed May 18, 2025, https://www.hfde.co.uk/resources/PD-detection-location-in-transformers-using-UHF.pdf

  24. Partial Discharge Testing of Transformers - Engineering.com, accessed May 18, 2025, http://files.engineering.com/download.aspx?folder=04b5752e-e1b0-4fbb-b50b-f5dc31449072&file=Partial_Discharge_Testing_of_Transformers.doc

  25. Multiple detections of insulation defects partial discharge in gas-insulated equipment - Frontiers, accessed May 18, 2025, https://www.frontiersin.org/journals/energy-research/articles/10.3389/fenrg.2022.937599/full

  26. Interpretation of Partial-Discharge-Activated Frequency Response Analysis for Transformer Diagnostics - MDPI, accessed May 18, 2025, https://www.mdpi.com/2075-1702/13/4/300

  27. (PDF) Interpretation of Partial-Discharge-Activated Frequency Response Analysis for Transformer Diagnostics - ResearchGate, accessed May 18, 2025, https://www.researchgate.net/publication/390488813_Interpretation_of_Partial-Discharge-Activated_Frequency_Response_Analysis_for_Transformer_Diagnostics

  28. Online Monitoring of Partial Discharges in Large Power Transformers Using Ultra-High Frequency and Acoustic Emission Methods: Case Studies - MDPI, accessed May 18, 2025, https://www.mdpi.com/1996-1073/18/7/1718

  29. Study on the Partial Discharge Characteristics and Development Process in Use of the Multiple Discharge Patterns for the Typical Defects in Gas-Insulated Switchgear | Request PDF - ResearchGate, accessed May 18, 2025, https://www.researchgate.net/publication/311528545_Study_on_the_Partial_Discharge_Characteristics_and_Development_Process_in_Use_of_the_Multiple_Discharge_Patterns_for_the_Typical_Defects_in_Gas-Insulated_Switchgear?_share=1

  30. Portable Partial Discharge Monitor Market Size & Trends [2025-2033], accessed May 18, 2025, https://www.globalgrowthinsights.com/market-reports/portable-partial-discharge-monitor-market-113537

  31. Emerging Trends in the Partial Discharge Monitoring Systems Market: Growth, Size, and Forecast for 2025 - SOUTHEAST - NEWS CHANNEL NEBRASKA, accessed May 18, 2025, https://southeast.newschannelnebraska.com/story/52506638/Emerging-Trends-in-the-Partial-Discharge-Monitoring-Systems-Market-Growth-Size-and-Forecast-for-2025/

  32. Cutting Energy Losses via Continuous Partial Discharge Monitoring - ModemTec, accessed May 18, 2025, https://modemtec.com/cutting-energy-losses-via-continuous-partial-discharge-monitoring/

  33. Partial Discharge: Uncovering Its Significance as an Indicator of Asset Health | Monitra, accessed May 18, 2025, https://www.monitra.com/news-and-events/partial-discharge-uncovering-significance

  34. What Is Partial Discharge Testing? | Vertiv Articles, accessed May 18, 2025, https://www.vertiv.com/en-asia/about/news-and-insights/articles/educational-articles/what-is-partial-discharge-testing/

  35. Quantifying the Economic Benefits of Online Monitoring - EA Technology, accessed May 18, 2025, https://eatechnology.com/media/31cnfrcc/white-paper-economic-benefits-of-online-monitoring.pdf

  36. Effect of Environmental and Operating Conditions on Partial Discharge Activity in Electrical Machine Insulation: A Comprehensive Review - IDEAS/RePEc, accessed May 18, 2025, https://ideas.repec.org/a/gam/jeners/v17y2024i16p3980-d1454205.html

  37. Efficient Partial Discharge Detection in Online Gas Insulated Switchgear Monitoring: Characterization Insights - OAKTrust, accessed May 18, 2025, https://oaktrust.library.tamu.edu/items/107122c3-0d19-40b9-bd59-4cba29693e84
